TOPEDGE 6362 Outrunner Brushless Motor-KV340
|
|
|
| Item No: |
OB6362-07 |
| Gross Weight: |
674g |
| Brand: |
TOPEDGE |
|
|
|
|
|
| Description |
|
Specifications:
KV: 340rpm/v
Non-load Current: 1.4A
Working Current: ¡Ü85A
Shaft Diameter: 8mm
N.W.: 563g
G.W.: 674g
Parameters:
| KV |
Non-load
Current |
Max
Working Current |
Loaded
Propeller |
Input
Voltage |
Working
Current |
Pull |
Output Power |
Rated Current |
Weight |
Shaft
(mm) |
Internal
Resistance |
| 340 |
1.4A |
85A |
1560 |
18.5V |
12.5A |
1700g |
231.3w |
72.5A |
563g |
8 |
0.0179¦¸ |
| 21V |
15A |
2200g |
315w |
| 22.2V |
17A |
2500g |
377.4w |
| 25.2V |
20.5A |
3100g |
516.6w |
| 29.4V |
27A |
4400g |
793.8w |
| 33.6V |
36A |
5600g |
1209.6w |
| 37.8V |
45A |
6800g |
1701w |
| 42V |
55.5A |
7800g |
2331w |

Size Reference:
Unit: mm
|
|
